Ahh, cool, I was given a panel that was very big, I think 20Hp, so I had a very similar idea. At the same time I will add the sub oscillator to this panel for the 3340VCO and switch it on or off with a switch. I think that would be very useful and you could even save a socket and a patch cable
1 Like
Finished a 4x4 Buffered Multiple on stripboard using 1161 schematics.
Lotās of cables hanging around and the board layout turned out to be uncomfortable tiny. But in the end it sounds rightā¦
Vintage front panel design!!!
4 Likes
I received a Robaux LL8 kit from Thonk a few hours ago itās a quick and easy build and Iām just really impressed with the module. Iām even considering selling my giant Doepfer Trigger matrix and building a second one of these in stead.
Oh, and those black thonkicons I got the other day came in handy for a blacked out look
7 Likes
My buddy made me a case for my Liquid Foam
He said heās probably going to stain it before he gives it back, canāt wait to see how it looks when its done!
10 Likes
Daaaaang! Beautiful!
3 Likes
Canāt wait to see or hear it in use.
4 Likes
Lots of cables, but very cool and above all helpful! I chose this option for not buffered. With mini patch cord
for 1.54 ā¬ including shipping
1 Like
I call itā¦ the Positivizer.
First time Iāve used one of these prototyping boards, I like it.
[Edit: Yeah, I noticed belatedly Iād left out bypass caps. I still havenāt added them in, and havenāt run into trouble yet, but part of me tells me I shouldā¦]
12 Likes
CC0 licence, thank you for that. I usually go for ISC or MIT or something, but CC0 fits the spirit of my work.
5 Likes
Where can i get this boards ? Did you made it yourself ?
2 Likes
Follow the link up there, thereās a repository including KiCad files and Gerbers.
2 Likes
Ah, okay, so Iāll have to get the boards made by JLCPCB or similar companies, right? Do you know if someone is already planning to do this, maybe a few more?
Iāve never had any made, or even made it myself, so I havenāt had any experience with it
1 Like
This would be a perfect first board to have made (since youāll want more than one for yourself) and itās fairly straight forward. Should be cheap too since itās not too big.
3 Likes
That sounds good, maybe I, or someone else here from the forum , can order a few more if someone is interested and then hand them over at cost price plus shipping costs ? Iāll check out how expensive it will be.
1 Like
Two buffered multiples built and tested. Live-streaming more soldering shortly.
EDIT: back online https://www.twitch.tv/heckseven
4 Likes
Finished. This is just a simple module whose sole purpose is to halve a control voltage and add 2.5V to it, so a Ā±5V signal gets converted to 0ā5V. Itāll be useful in conjunction with dac/ino, until someday I get around to redesigning the latter to take Ā±5V inputs.
2 Likes
I think you mean āgateway drug.ā Iām going to hold off on the bespoke engineering even in this case. Canāt say Iām not highly tempted though.
2 Likes
Iāve already tried to build 2 different noise modules and both didnāt work
. So I just took a small radio and amplified the signal with a TL072 on a modular level. Now I have to conjure up a panel for it. I think you can do cool things with it. Omri Cohen, for example, very often sends a radio signal to the Clouds module and does crazy things with it! ā¦ Now all thatās missing is a Clouds * naarf * Does anyone have a stripboard layout for it?
Here is a video from the very talented Omri Cohen with a good example
5 Likes
I think Iāll leave the STM32 on a stripboard for someone else to try.
2 Likes
