oh whoops, totally forgot to update on that…
All my projects are slowed down this month, as I’m moving to a new flat, and starting a new job…
So far, the random CV and duration are working well, I know how to fix the chorus CV, and I didn’t test the chorus duration.
Basically, the circuit output sequentially 16 random CV with random duration, then the same thing, but with durations that follow a pattern stored in the ROM (the PLCC chip). And it loops like that again and again, each time with a different random part, but the same chorus.
haven’t been able to buy shit for the last month . so I had a nice surprise when these IC’s from Electric Druid show up. I had forgotten all about them [ shipped Aug. 17 ]
2 @ vclfo 10
4 @ AS3310
4 @ AS3320
now I can build some of https://www.eddybergman.com/ 's strip board stuff . great site by the way if you want to do some strip board based modules, good pictures , schematics , etc.
3310, I need to take a second look at mine. I PCB’d it based on the data sheet and Eddys revisons but it did not work. But I did make an arse of the build. That was back in July and it’s sat in a box since…
I just got a notification from our Alexa device that based on my order history it’s probably time to buy more 1/4" jacks
Which would probably be true if I had this interface for my sequencer working and added all the gates/triggers it can support. But since that’s not working yet I can probably get by another week or two I actually have a few more jacks on hand than expected
So these are Eurorack sized that I’ve done. Designing a Kosmo sized panel for the MI modules wouldn’t be too much more work if I used the same design as the one I created for the Eurorack panel. For me, the challenge would be modifying the PCB in order to make it easier to jumper over. Though I guess you could just run wire over like @devicex does. The boards I’m using are all SMD. Most I picked up from amazingsynth.com out of the UK as his boards are really good quality. (I learned the hard way that a cheaper PCB for SMD work can make your life more difficult in doing successful builds of these particular modules.)
If you do make the boards yourself then you can probably sell off your extras easily. I might even buy a few from you depending on which modules you choose. I have quite a few MI modules that I’m designing panels for because while the Magpie panels are awesome they are expensive and when you need 10 - 15 different panels it’s a lot of money. The Oscillasaurus panels are okay (I have a few) but they don’t display the logo, some of the icons, and have changed the wording on some of the labels to things that are less helpful for me personally.
The Transistor Ladder Filter, and a new Panel for the Switched Mult (I gifted mine to a local who bought just the pcb back before cory had panels for it)
And a freaking CGS202 SERGE EQ (Resonant Equalizer)
If you think 9 mm vertical B100ks are hard to find, try 9 mm vertical B100k dual gangs. Literally I could not find these anywhere but Thonk. Even Mouser seems not to carry them (or has hidden them well). While I was at it I ordered a board for a VC Fader, not that that’s something I feel any urgency about but why not, it was there.
